AFCO Racing 3860BGX BIG GUM X “RADIALS” DOUBLE ADJUSTABLE COIL-OVER, 6 in. Strok
Specifications
| Return Shipping Will Be Paid By | Buyer |
| Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand | Afco Racing Products |
| SKU | AFC3860BGX |
| Manufacturer Part Number | 3860BGX |
| Coil-Over Shock Type | Double-adjustable |
| Shock Body Material | Aluminum |
| Shock Body Finish | Blue anodized |
| Adjustable Valving | Yes |
| Extended Length (in) | 18.920 in. |
| Collapsed Length (in) | 13.000 in. |
| Upper Mount | Bearing |
| Lower Mount | Bearing |
| Internal Design | Twin-tube |
| Body Diameter (in) | 2.150 in. |
| Recommended Spring Diameter (in) | 2.625 in. |
| Recommended Spring Length (in) | 12-14 in. |
| Suggested Ride Height | 14.75 - 16.75 in. |
| Quantity | Sold individually |
| Universal | Yes |
| Usage | Drag Radial |
Description Double Adjustable - broadest range of adjustment in industry.Big Gun X Valving -specifically valved for high horsepowerdrag radial tire applications.Great for BIG or SMALL tire door slammers.Rebuildable and revalvable The Big Gun X Double Adjustable Twin Tube shocks are specifically valved for high horsepower drag radial tire equipped applications. Drag radial competitors require a unique valving package to control the rear suspension and properly apply the radial tire to the track. Superior traction is achieved through a high flow piston that delivers consistent performance, pass after pass. If you have 1,000 - 1,500 horsepower and are on a drag radial tire, this is the valving package you need to complement your race program. For quicker adjustments, mount your AFCO shocks upside down for unsprung weight savings and ease in accessing the rebound adjuster. Specifications SpecificationCoil-Over Shock TypeDouble-adjustableShock Body MaterialAluminumShock Body FinishBlue anodizedAdjustable ValvingYesNumber of Valving Selections62Extended Length (in)18.920 in.Collapsed Length (in)13.000 in.Upper MountBearingLower MountBearingInternal DesignTwin-tubeGas ChargedNoBody Diameter (in)2.150 in.Coil-Over Springs IncludedNoRecommended Spring Diameter (in)2.625 in.Recommended Spring Length (in)12-14 in.Adjustable Mounting Bracket IncludedNoHardware IncludedNoSuggested Ride Height14.75 - 16.75 in.QuantitySold individuallyNotesDesigned for drag radial tire applications.UniversalYesUsageDrag RadialItem #AFC3860BGXMfg Part #3860BGX Powered by
